With Virtek laser projectors there’s no need to refer to blueprints or use a measuring tape, so even the most complicated trusses, wall panels, and modular systems can be built quickly and accurately. These systems are so easy to use, even new employees can immediately contribute to your bottom line.
.png){kind=logo}
Laser Templating Solution.
Facilitate assembly of trusses for roof, floor, cassettes and wall panels.
Virtek® IRIS Truss
How does Virtek improve truss assembly with better quality? The Virtek IRIS Truss System projects a laser template of the truss to be built onto the work surface, highlighting the position and shape of all truss joints and connector plates. This eliminates the need for measuring, squaring and stringing.
Best Suited For:
- Roof & Floor Truss
- Handrail
- Pattern Cutting
- Floor Grate Cutouts
- Wall Panel Assembly
- Visual Inspection (Hardware and Contours)
- Pre-Fab Concrete
- Cnc Routing/Machining Setup
- Square Tube Framing and Sub-Assemblies
- Assembly/Layout Tasks Performed on Welding Tables
Don't see your application? Just ask, we can help!
Case Study: Rafters & Walls
Component Placement
Rafters and Walls provides custom built roof and floor trusses as well as wall panels for both residential and commercial projects in the Piedmont area of North and South Carolina.
“Rafters & Walls have been using Virtek lasers for 5 years. It’s great to have the ability to train our employees in a very short order. We build complex roof and floor trusses with ease with Virtek laser technology.”
Richard Pedde, Owner
Case Study: TRS Components
Component Placement using Laser Templating
Since integrating Virtek’s laser systems, TRS Components has experienced a remarkable 65% increase in efficiency in their building components production. This cutting-edge laser technology enables precise measurements and accelerates assembly processes, ensuring that each component meets exacting specifications. The TRS team leverages the system to accurately position studs and blocking in wall panels, a critical step that not only speeds up production but also minimizes errors.
Case Study: McCabe Lumber
Component Placement
A clear challenge: Increase Productivity by Reducing Setup Time
At McCabe Lumber we want to be more than just a place to get materials. We want to be your project partner, offering you access to an extensive inventory backed by a knowledgeable and experienced staff who will help you find the perfect solution for your project.
"Virtek Lasers helps take the guess work out of building and gives time back to the station that would normally have been wasted measuring or over jigging to ensure the quality from one truss to the next. "
Mike Kraft, Production Manager
Our Products
Virtek Iris™ 3D with the Vision Positioning System (VPS) significantly advances laser-guided assembly with innovative “Flash Align” functionality and superior laser-line visibility. Initial alignment is 20X faster and re-alignments are reduced from minutes to seconds – save time, increase workflow all while retaining quality and accuracy.
Industries: Aerospace & Composites, Industrial Fabrication, Defense, Wind
The Virtek® IRIS Truss system projects a laser template of the truss to be built onto the work surface, highlighting the position and shape of all truss joints and connector plates. This eliminates the need for measuring, squaring and stringing.
Industries: Component Manufacturing
Elevate quality control with the IRIS™ AI Camera—engineered for composite inspection and process monitoring. This smart camera inspects defects like FOD, and missing nails/nail embedment, and incorrect truss plates instantly. Capture high-definition images throughout the build process, generate real-time inspection reports, and integrate seamlessly with your existing laser projection systems for full traceability and production insight.
Learn More: Composite Inspection Process Monitoring
Industries: Aerospace & Composites, Component Manufacturing, Industrial Fabrication
The Virtek Laser Template Generator™ (LTG) system projects a template that shows operators the exact location of all important features in each component or assembly. There’s no need to refer to blueprints or the use of a measuring tape, so even the most complicated designs can be built in minutes.
Industries: Aerospace & Composites, Component Manufacturing, Industrial Fabrication
Virtek® LaserQC® is a rapid inspection system that employs lasers to measure the accuracy of two-dimensional parts to tolerances within 0.05mm (0.002 inches).
Industries: Sheet Metal Gaskets
